氣壓裁銲機 PSW-168
Product Categories
Click image to view full sizeItem-Name:
Specification:
PneumaticPortable Shear Welder
Specification:PneumaticPortable Shear Welder
Country of Origin：Taiwan
Model：PSW Service
More-Details:
1 . Shearing Unit：Pneumatic System
2 . Strip Width：Suitable for plate widths from 168 to 380 mm
3 . Strip Thickness：Suitable thickness (T): 1.0 - 2.0 mm (Custom thickness available upon request)
4 . Welding Equipment：Compatible with TIG welding
Portable Shear Welder (Pneumatic series) | ||||
Model | PSW-68 | PSW-250 | PSW-320 | PSW-380 |
Input Power | 1Φ, 220V | |||
Strip Width | 168 mm | 250 mm | 320 mm | 380 mm |
Strip Thickness | 2.0 mm | |||
Shearing System | Pneumatic | |||
Clamping System | Pneumatic | |||
TIG Welder | 200A | |||
Dimension (L×W×H) | 800×600 ×1540 mm | 920×600 ×1540 mm | 1000×600 ×1540 mm | 1100×600 ×1540 mm |
More Products
Hydraulic Portable Shear Welder
1. Shearing Unit ：Hydraulic System2. Strip Width：pplicable for plate widths from 168 to 420 mm3. Strip Thickness：pplicable thickness T: 1.0 to 4.5 mm (Customizable thickness available upon request)4. Welding Equipment：Compatible with TIG welding (Tungsten Inert Gas welding) Portable Shear Welder (Hydraulic series) Model PSWH-168 PSWH-250 PSWH-320 PSWH-380 PSWH-420 Input Power 3Φ, 220V Strip Width 168 mm 250 mm 320 mm 380 mm 420 mm Strip Thickness 2.5 mm 4.0 mm 4.5 mm Shearing System Oil Hydraulic Clamping System Hydraulic System TIG Welder 200A 300A Dimension (L×W×H) 800×600 ×1540 mm 920×600 ×1540 mm 1000×600 ×1540 mm 1100×600 ×1540 mm 1200×600 ×1640 mm
油壓裁銲機 PSWH-380
1. 裁切裝置 : 油壓系統 2. 片條寬度 : 適用板寬168~420mm 3. 片條厚度 : 適用厚度T:1.0~4.5mm(可適用厚度訂作) 4. 銲接設備可適CO2或TIG銲接(厚度T:4.0mm,適用CO2銲接 )
